- All in one: Print/Scan/Copy/Fax
- 2pl ink droplet and 4800dpi photo print resolution
- 4-color ink system with dedicated black ink for B&W document printing
- On-Top-Cover Operation Panel for Convenient Scanning
- Liftable Scanner Cover for Scanning Large-size Books
- 30-sheet Auto document feeder for multi page scan/copy
- Built-in Wi-Fi for wireless network print/scan/out going fax
- Caller ID and Junk fax rejection
- Save fax to USB drive function
- New Auto Document Fix function
- New Auto Photo Fix II function
- Direct scan PDF/JPEG file to USB drive
- Built-in PictBridge direct print and optional Bluetooth unit* for wireless printing
*Optional bluetooth unit BU-30 |
- Canon Mx340 Scanner Driver Download
- Canon Mx340 Scanner Drivers
- Mx340 Scanner Driver
General Specifications| Printing resolution (dpi) | 4800* (horizontal) x 1200 (vertical)
* Ink droplets can be placed with a pitch of 1/4800 inch at minimum. | | Interface | USB Port:
Hi-Speed USB *1
Direct Print Port:
PictBridge
Bluetooth v2.0 (Option) *2 *3 *4
USB flash drive
LAN Port:
Wireless LAN: IEEE802.11b/IEEE802.11g *5
*1 A computer that complies with Hi-Speed USB standard is required. Sincethe Hi-Speed USB interface is fully upwardly compatible with USB 1.1,it can be used at USB 1.1.
*2 Maximum speed: 1.44 Mbps
*3 JPEG/PNG only
*4 Bluetooth connection is for printing only.
*5 Setup possible through Easy setup, WPS (Wi-Fi Protected Setup) or WCN (Windows Connect Now). | | Print width | 8 inches /203.2 mm
(for Borderless Printing: 8.5 inches/216 mm) | | Operating environment | Temperature: 5 to 35°C (41 to 95°F)
Humidity: 10 to 90% RH (no condensation) | | Storage environment | Temperature: 0 to 40°C (32 to 104°F)
Humidity: 5 to 95% RH (no condensation) | | Power supply | AC 100-240 V, 50/60 Hz | | Power consumption | Printing (Copy): Approx. 11W
Standby (minimum): Approx. 2.2W*
OFF: Approx. 0.8W*
* USB connection to PC | | External dimensions | Approx. 18.1 (W) x 16.4 (D) x 7.8 (H) inches
Approx. 458 (W) x 415 (D) x 198 (H) mm
* With the Paper Support and Paper Output Tray retracted. | | Weight | Approx. 8.6 kg (Approx. 19.0 lb)
* With the FINE Cartridges installed. | | Canon FINE Cartridge | Black: 320 nozzels
Color: 384 x 3 nozzels | | ADF capacity | A4 or Letter size: Max. 30 sheets (20 lb/75 gsm paper), up to 0.16 inches/4 mm in heightLegal size: Max. 5 sheets (20 lb/75 gsm paper),up to 0.04 inches/1 mm in heightOther sizes: 1 sheet | |
Download drivers, software, firmware and manuals for your Canon product and get access to online technical support resources and troubleshooting. PIXMA MX347 Smart Office All-in-One photo printer equipped with Wi-Fi for wireless network print and scan, to meet the diverse needs of its users and provide the ideal printing solution for every small office, SOHO and household that incorporates high quality, versatile.
Canon Mx340 Scanner Driver Download
Scan Specifications| Scanner driver | TWAIN/WIA (for Windows 7/Windows Vista/Windows XP) | | Maximum scanning size | A4/Letter, 8.5 x 11.7 inches/216 x 297 mm (Platen Glass)/8.5 x 14.0 inches/216 x 356 mm (ADF) | | Scanning resolution | Optical resolution (horizontal x vertical) max: 1200 dpi x 2400 dpi
Interpolated resolution max: 19200 dpi x 19200 dpi | | Gradation (Input/Output) | Gray: 16 bit/8 bit
Color: 48 bit/24 bit (RGB each 16 bit/8 bit) | |
Fax Specifications
| Applicable line | Public Switched Telephone Network (PSTN) | | Communication mode | Super G3, G3 | | Data compressing system | Black: MH, MR, MMR
Color: JPEG | | Modem speed | Max. 33.6 kbps
(Automatic fallback) | | Transmission speed | Black: Approx. 3 seconds/page at 33.6 kbps
(Based on ITU-T No.1 chart for US specifications and Canon FAX Standard
chart No.1 for others, both in standard mode or Canon FAX Standard chart No.1, standard mode.)
Color: Approx. 1 minute/page at 33.6 kbps(Based on Canon COLOR FAX TEST SHEET.)
| | Gradation | Black: 256 levels
Color: 24 bit Full Color (RGB each 8 bit) | | Density adjustment | 3 levels | | Memory | Transmission/reception: approx. 50 pages
(Based on ITU-T No.1 chart for US specifications and Canon FAX Standard chart No.1 for others, both in standard mode.) | | Fax resolution | Black Standard: 8 pels/mm x 3.85 lines/mm
(203 pels/inch x 98 lines/inch)
Black Fine, Photo: 8 pels/mm x 7.70 lines/mm(203 pels/inch x 196 lines/inch)
Black Extra fine: 300 x 300 dpi
Color: 200 x 200 dpi | | Dialing | Automatic dialingCoded speed dial (max. 20 destinations)
Group dial (max. 19 destinations)
Regular dialing (with Numeric buttons)
Automatic redialing
Manual redialing (with the Redial/Pause button/max. 10 destinations) | | Others | Activity report (after every 20 transactions)
Sequential broadcasting (max. 21 destinations)
Rejected numbers (Max 10 destinations) | |
Canon Mx340 Scanner Drivers
Network SpecificationsCommunication
protocol | TCP/IP | | Wireless LAN | Supported Standards: IEEE802.11g/IEEE802.11b
Transfer speed:
IEEE802.11g: 6/9/12/18/24/36/48/54 Mbps
IEEE802.11b: 1/2/5.5/11 Mbps
Frequency bandwidth *1: 2.412-2.462 GHz or 2.412 GHz-2.472 GHz
Channel *1: 1-11 or 1-13
Communication distance: Indoors 50 m *2
Security: Encryption by WPA-PSK, WPA2-PSK, or WEP (64/128 bits),
and access control by passwords
*1 Frequency bandwidth and available channels differ depending on country or region.
*2 Effective range varies depending on the installation environment and location. | |
Mx340 Scanner Driver
Copy Specifications| Multiple copy | Max 99 pages | | Intensity adjustment | 9 positions, Auto intensity (AE copy) | | Reduction/Enlargement | 25% - 400% (1% unit) | |
